Gigahertz-solutions HFE35C High Frequency Analyzer Measures Precise High Frequency Radiation

Measure high-frequency radiation with the HFE35C high-frequency analyzer set in order to determine suitable remedial measures. High-quality set with the following components:

• Actual measuring device based on the HFE35C, only with extended frequency range down to 27 MHz.
• Specifically compensated LogPer antenna for the range above 800 MHz.
• Horizontal isotropic ultra wideband antenna UBB27_G3 from 27 MHz to above 2.7 GHz (limited by the frequency response of the HFE35C).
• Small plastic case K5 with foam insert for safe transport of the measuring device with the two antennas.

Specifications of the HFE35C high-frequency analyzer set:

• Frequency range: 27 MHz up to over 2.7 GHz
• Measuring range: Power flux density: 0.1 - 1999 µW/m²
• Accuracy: Basic accuracy including linearity error: +/- 6 dBZero point deviation and special digitization error ("rollover"): +/- 9 digits
• Sensor: Logarithmic-periodic measurement antenna with frequency response compensated directly on the antennaQuasiisotropic ultra wideband antenna ("omni antenna") adjusted for vertically polarized fields
• Audio analysis: Modulation frequency and field strength proportional audio signal supports the identification of pulsed radiation sources (GSM, DECT, etc.) and the detection of increased exposure.
• Power supply: 9-volt E-block alkaline manganese battery (included), average operating time: 4 - 7 hours (depending on operating mode)Low battery indicator, Auto power off function
• Signal evaluation: Peak value and average value display
• Other: Two years warranty
• Weight: 1.06 kg

Scope of delivery:

• Measuring instrument
• Pluggable LogPer and UBB antenna
• Detailed operating instructions with neutral background information
• Delivery in case
